Product Range:
- Size: NPS 2”- 48”, DN 50 -1200
- Pressure rating: class150-2500, PN16-420
- Basic design: API6D, EN 13942
- Face to face dimensions: ASME B16.10
- Face to face dimensions: EN 558-1(flanged ends), EN 12982(welding ends)
- Connecting dimensions: ASME B16.5(≤ 24” flanged ends), ASME B16.47(≥26” flanged ends), ASME B16. 25(welding ends)
- Connecting dimensions: EN 1092-1 (flanged ends), EN 12627 (welding ends)
- Operation: lever, worm gearing, electric actuator, pneumatic actuator, hydraulic actuator, gas over actuator
Design Specifications:
- Design: API599 API6D
- Pressure-temperature rating: ASME B16.34
- Face-to-face dimensions for butt weld and flanged valves: ASME B16.10
- Flange design: ASME B16.5
- Butt welding design: ASME B16.25
Body Material:
A216-WCB (Carbon Steel), A217-WC6 (1-1/4Cr-1/2Mo), A217-WC9 (2-1⁄4Cr–1Mo), A217-C5 (5Cr–1⁄2Mo), A217-C12 (9Cr–1Mo), A352-LCB (Carbon Steel), A352-LCC (Carbon Steel), A351-CF8M (18Cr–9Ni–2Mo), A351-CF3M (18Cr–9Ni–2Mo)
Pressure Testing:
Each valve is pressure tested in accordance with API 6D, API 598, or special customers' requirements as applicable.
